| Category |
Cylinder Block |
| Name |
Oil Level Gauge |
| Parts No |
6135-21-5320 6135215320 |
| Engine Number |
6D105-1U S4D105-5A S4D105-5B |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT |
| Packing |
As request or standard packing |
- Key functions & working principle
| Working Principle |
1. The gauge is inserted into the dedicated oil level tube (on engine sump, hydraulic reservoir, or transmission case) until fully seated |
| 2. When removed, the oil adheres to the graduated shaft, indicating the current oil level |
| 3. The "MAX" and "MIN" marks define the safe operating range – oil level must be between these two indicators |
| 4. The O-ring creates a seal between the gauge and tube, preventing oil from leaking out and contaminants from entering the system |
| Core Functions |
1. Accurate Oil Level Measurement: Provides real-time data to ensure oil is within the safe operating range |
| 2. Prevent Oil Starvation: Alerts operators to low oil levels, avoiding engine/hydraulic component wear (e.g., bearing damage, pump seizure) |
| 3. Avoid Overfilling: Prevents excessive oil from causing foaming, overheating, or seal damage |
| 4. Contamination Protection: Sealing O-ring blocks dust, debris, and moisture from entering the oil system |
| 5. Simplify Maintenance: Quick, tool-free operation enables frequent oil level checks (critical for heavy-duty equipment) |
ENGINES 6D105-1U S4D105-5A S4D105-5B Komatsu
- More other gauge applied to KOMATSU heavey machine
| 1282 544 H1 GAUGE, CONVERTER OIL PRESSURE |
| KOMATSU |
| |
| 22T-75-27140 GAUGE |
| LW100 |
| |
| 287-15-11620 GAUGE |
| WS23S |
| |
| PC0317 GAUGE, FUEL |
| 330M, HD785 |
| |
| 22T-05-15360 GAUGE,TEMPERATURE |
| LW100, LW250 |
| |
| 22T-05-15371 GAUGE,FUEL |
| LW100, LW250 |
| |
| 714-07-14611 GAUGE,LEVEL |
| WA400, WA420, WA450, WA450L, WA470, WF450, WF450T |
| |
| 125-43-22370 GAUGE,OIL |
| D40A, D40PL, D45A, D45P |
| |
| 11T-06-12120 GAUGE,ANGLE |
| BC100 |
| |
| 154-21-11621 GAUGE |
| D80A, D80P, D85A |
| |
| 933 022 C1 GAUGE, SIGHT |
| KOMATSU |
| |
| 131-04-11141 GAUGE |
| D50S |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
6136-22-1020 |
[1] |
CYLINDER BLOCK ASS'Y Komatsu |
170 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6136221021"] |$0. |
|
| |
6136-22-1101 |
[1] |
CYLINDER BLOCK A. Komatsu |
170 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6136221020", "6136221021"] |$1. |
|
| 2 |
6136-21-1410 |
[4] |
BUSHING,CAMSHAFT Komatsu OEM |
0.05 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 3 |
6136-29-1210 |
[6] |
CAP,MAIN METAL Komatsu |
1.614 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 4 |
6136-29-1220 |
[1] |
CAP,MAIN METAL Komatsu |
1.82 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 5 |
04020-00514 |
[1] |
PIN,DOWEL Komatsu |
0.002 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 6 |
6136-22-1710 |
[14] |
BOLT Komatsu |
0.22 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 7. |
6130-11-1420 |
[2] |
PLUG,EXPANSION Komatsu |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 8. |
6136-21-1911 |
[2] |
PIN,DOWEL Komatsu |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6136211910"] |
|
| 9. |
04025-00512 |
[1] |
PIN,SPRING Komatsu |
0.001 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 10. |
04020-01228 |
[4] |
PIN,DOWEL Komatsu |
0.026 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["21T3016190"] |
|
| 11. |
04025-00408 |
[6] |
PIN,SPRING Komatsu |
0.001 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 12. |
07040-11209 |
[1] |
PLUG Komatsu |
0.028 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 13. |
07005-01212 |
[1] |
GASKET (K2) Komatsu China |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6731715870", "R0700501212"] |
|
| 14. |
07043-50211 |
[2] |
PLUG Komatsu |
0.012 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 15. |
07043-50108 |
[3] |
PLUG Komatsu |
0.005 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["0704300108", "0704320108", "820510607", "YM23871010000"] |
|
| 16. |
04025-00820 |
[2] |
PIN,SPRING Komatsu China |
|
| |
|
|
["SN: 52271-UP"] analogs:["YM22351080020", "1118628870", "20G2222660"] |
|
| 17 |
6136-21-2210 |
[6] |
LINER,CYLINDER Komatsu OEM |
4.22 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6137222210"] |
|
| 18 |
6136-21-2220 |
[6] |
SEAL,CREVICE (K2) Komatsu OEM |
0.011 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 19 |
6136-21-2230 |
[6] |
O-RING,UPPER (K2) Komatsu China |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 20 |
6136-21-2240 |
[6] |
O-RING,LOWER (K2) Komatsu China |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 21 |
6136-21-2410 |
[1] |
SHAFT,IDLER Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 22 |
04025-00316 |
[1] |
PIN,SPRING Komatsu |
0.001 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 24 |
6136-21-2420 |
[1] |
PLATE Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 25 |
01010-31275 |
[1] |
BOLT Komatsu |
0.082 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 26 |
09605-01332 |
[1] |
PLATE, NAME,(ENGLISH) (LIMITED SUPPLY) Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 27 |
04418-02550 |
[4] |
SCREW Komatsu |
0.001 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["0441812550"] |
|
| 28 |
6136-21-7811 |
[1] |
GASKET (K2) Komatsu |
0.007 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["6136217830"] |
|
| 29 |
01010-31030 |
[4] |
BOLT Komatsu China |
0.03 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["01010E1030"] |
|
| 30 |
01602-01030 |
[4] |
WASHER,SPRING Komatsu |
0.004 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["0160211030"] |
|
| |
6136-21-7300 |
[1] |
OIL FILLER ASS'Y Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |$32. |
|
| 31. |
6136-21-7280 |
[1] |
FILLER,OIL Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 32. |
6136-21-7120 |
[1] |
CAP ASS'Y Komatsu |
0.1 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 33 |
6136-21-7180 |
[1] |
GASKET Komatsu |
0.006 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 34. |
6136-21-7190 |
[1] |
CHAIN Komatsu |
0.01 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 35 |
6135-21-5320 |
[1] |
GAUGE,OIL Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 36 |
6136-21-5460 |
[1] |
GUIDE,OIL GAUGE Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 37 |
6136-21-5650 |
[1] |
BRACKET Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 38 |
6114-21-5170 |
[1] |
CLAMP Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 39 |
01010-30820 |
[1] |
BOLT Komatsu |
0.013 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["01010E0820"] |
|
| 40 |
01602-00825 |
[1] |
WASHER,SPRING Komatsu |
0.004 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["0160220825", "0231011020", "6124613790"] |
|
| 41 |
01641-20812 |
[2] |
WASHER Komatsu |
0.005 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["YM22117080000"] |
|
| 42 |
01580-00806 |
[1] |
NUT Komatsu |
0.005 kg. |
| |
|
|
["SN: 52271-UP"] |
|
| 43 |
6136-71-5730 |
[1] |
BRACKET Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 48 |
6128-11-5872 |
[1] |
CLAMP Komatsu China |
|
| |
|
|
["SN: 52271-UP"] |
|
| 49 |
01010-31025 |
[1] |
BOLT Komatsu China |
0.03 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["01010E1025", "0101061025", "0104041025"] |
|
| 50 |
01641-01016 |
[1] |
WASHER Komatsu |
0.002 kg. |
| |
|
|
["SN: 52271-UP"] analogs:["0164121016"] |
|
- We could supply the following spare parts
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
